GlobTek's GT-91093-HPOE Power over Ethernet Midspan family offers cost effective and reliable solution for remote powering of Wireless LAN Access Points, Voice over IP phones, Security Cameras, RFID readers and other IP terminals up to 38.5 Watts over existing network infrastructure. GlobTek PoE Midspan can be configured to 15.4 watts of power per port over two pairs in compliance with IEEE 802.3af standard or to 38.5 watts over four pairs of the CAT5e cable. When the load device is connected, GlobTek's PoE Midspan will initiate automatic detection and classification processes and only those terminals that are found valid will be powered. GlobTek's PoE Midspan is designed to function with and provide power to any IEEE 802.3af compliant PoE devices.

Features:
- High Power Multiport PoE Midspan delivers up to 38.5W per port
- Midspan can be configured to 15.4W per port for IEEE 802.3af compliance
- Four Pair Power Injection Method for High Power PoE and Two pair for IEEE 802.3af version
- High Power PoE can power standard Powered Devices ("af" PDs) without Modifications
- Scalable 6, 12, 18 or 24 port models available
- IEEE 802.3af Detection, Classification, Disconnect and Overload Protection
- No Minimum Load Required to Maintain Port Power
- 300 Watts Full PoE Midspan Power for standard version, Expandable up to 1000 Watts
- Integrated Power Management with Port Prioritization Technology
- LED User Interface for every Port for Power Good and Fault Condition
- Designed to meet 10/100/1000 BaseT Data Rates
- Universal Input Power from 100Vac to 240Vac
- Full Protection for Over Voltage, Current and Temperature
- Compact 19 inch rack, 1U height

Applications:
VoIP Phones, VoIP Phone with Video, Wireless Access Points, Bluetooth Access Points, Multi-Band Wireless Access Points, Network Security Cameras, Point of Sales, Industrial Controllers, Electronic Time Card Readers, Building Security Systems, Network Camera with Pan, Tilt and Zoom Features, Electronic Signs, RFID Readers, Motion Sensors, HVAC Controllers, Magnetic Card Readers, PDAs. GlobTek now offers a 5-year warranty for products manufactured starting July 2007

GlobTek's GTM91094 series of Desktop Charging Cradles meet international Class II, Double-Enforced Insulation Mechanical Configurations, Regulated Output voltage from: 5V to 48Vdc in 0.1V increment, up to 6W of continuous output power. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Case, Thermal Conduction Cooling, Case Dimensions: 107.5 x 76 x 45 mm. This Family features: Regulated output with very low ripple, Built-in Protection features: O.C., S.C., O.V., Thermal, accepts Universal Input: 90-264Vac, designed meet safety agency requirements: UL /cUL 1950/60601.1 and TUV EN60950/ 60601.1 and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B for ITE/Medical Applications. Ideal for charging hand held devices in portable instrumentation and tele/data communication applications. Modified, Custom and Higher Wattage Designs are also available. GlobTek now offers a 5-year warranty for products manufactured starting July 2007.

GlobTek’s GT-41076 (up to 6W), GT-41052 (up to 15W) and GTM41060* (up to 25W w/Constant Current option) series of Wall-Interchangeable Blade Wall Plug-In North America, Europe, U.K., Australia, China, Korea Class II, Double-Enforced Insulation Mechanical Configurations, Regulated Outputs voltage from: 5V to 48Vdc in 0.1V increments, up to 25W of continuous output power. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Upper and Lower Case, Thermal Conduction Cooling, Case Dimensions: 64L x 40.5W x 29H (mm). This Family features: Regulated output with very low ripple, Built-in Protection features: O.C., S.C., O.V., Thermal, accepts Universal Input: 90-264Vac, meets Safety Agency Requirements: UL /cUL 1950/*60601.1 and TUV EN60950/ *60601.1 and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B for ITE/Medical Applications. All Models carry UL, TUV and T-Mark logos and CE-Mark. Reports including CB are generated by independent Certified Laboratory. Modified and Custom Designs are Also Available. GlobTek now offers a 5-year warranty for products manufactured starting July 2007.

GlobTek's GTM91092-100-M series delivers up to 111W of Continuous Output Power and has 5 regulated outputs: +5Vdc @ 10A, +5Vdc @ 1.5A, -5V @ .75A, 130Vdc @ .15A (externally programmable) and +12Vdc@ 2.5A. This High Efficiency, Series of Power Supplies Features: optional Aluminum U-Channel Chassis with Optional Top Cover, Remote Voltage Sensing, Active PFC, accepts Universal Input: 90-264 Vac, Low Ripple, Class B EMI Filter, Built-in Protection: O.C./S.C., O.V., O.T., Footprint size starts at 64.5 in2. Meets Safety Agency Requirements: UL /cUL / TUV 60950/60601.1 and complies with EMC Directives for CE and FCC Class B Applications. Modified and Custom Designs are Also Available .

GlobTek's GT-91085-3550 Power over Ethernet (PoE) Active Injector offers a compact and cost effective, solution for remote powering of Wireless LAN (WLAN) Access Points, Voice over IP phones and network security cameras. The injector is designed to meet the anticipated requirements of IEEE 802.3at, but modifications may be required since this standard has not yet been finalized or released. The Active Injector automatic detection and protection of legacy Ethernet terminals, eliminates the need for external power supply and its associated AC/DC power cabling, providing a compact, affordable, safe and reliable power solution over existing Ethernet infrastructures. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Case, Thermal Conduction Cooling, Case Dimensions: 125mm (d) * 75mm (w) * 38mm (h). This Family features: Regulated output with very low ripple, Built-in Protection features: O.C., S.C., O.V, detection circuit, Thermal, LED to indicate Power & POE "OK". Unit accepts input voltage from 90-267Vac 47-63Hz. Power & Data connectors can be installed to meet customer's requirements. Modified and Custom Designs are Also Available.

GlobTek Inc. introduces the latest series of 100-120W desktop power supplies, output voltages from: 3.3V to 48V in 0.1V increment, single-platform design. This family of Desktop Style power supplies is housed in Impact Resistant Polycarbonate Enclosure, Thermal Conduction Cooling, Case Dimensions: 5.60L x 3.00W x 1.7H (in), all Models. This Family features: Regulated output with low ripple single/dual/triple up to 120W, Remote Sensing, has Built-in Protection features: O.C./S.C., O.V., Thermal, accepts Universal Input:100-250VAC, meets Safety Agency Requirements: UL/Demko/CCC/C-Tick 60601-1, and complies with EMI/RFI Regulations, EMC Directives/ CE Compliant for Grounded and Non-Grounded Applications. Power Factor Correction (PFC) is available, standard option, to comply with EN61000-3-2 and EN61000-3-3. Modified and Custom Designs, such as: Constant Current, Battery Chargers, Internal Applications: PCB and Open Frame Mounted are Also Available.

Class II + FE, Double-Enforced Insulation. Regulated output voltage of 24Vdc up to 96W of continuous output power. Enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Case, Thermal Conduction Cooling, Case Dimensions: 176.5x74.0x40.0 (mm). This Family features: Regulated output with very low ripple, Built-in Protection features: O.C., S.C., O.V., Thermal, accepts Universal Input: 90-264Vac, meets Safety Agency Requirements: UL /cUL to 1313 and CE/TUV to 60950-1 and complies EMC Directives for CE, VCCI, and FCC Class B Applications. All Models carry UL, CE, Demko, PSE and CE Logos with Reports generated by independent Certified Laboratory. Modified and Custom Designs are also available.

Now available! Desktop Switching power supplies from 12-24VDC with European approval for EN60335-1, household and similar electrical appliances. 60W, 12-124v power supplies. These RoHS compliant power supplies are housed in Impact Resistant Polycarbonate Enclosure, Thermal Conduction Cooling, Case Dimensions: 119 X 60 X 32 MM. This Family features: Regulated output with low ripple up to 50W output power, Remote Sensing, has Built-in Protection features: O.C./S.C., O.V., Thermal, accepts Universal Input: 100-250VAC, meets Safety Agency Requirements: Innova/GS to EN60335-1 (1st Edition) and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B, for Grounded, Class I or Class II ITE Applications. Input connector may be IEC60320/C8. Modified and Custom Designs, such as: Constant Current, Battery Chargers, Internal Applications: PCB and Open Frame Mounted are Also Available.

GlobTek has added 48VDC output models to it's series of 15W interchangeable blade power adapters. GT-41052-1548 Wall-Plug-In with optional North America, Europe, U.K., Australia, Korea, Argentina, China plug attachments. Model is Class II, Double-Enforced Insulation. Regulated Output voltage of 48VDC with up to 15W of continuous output power. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Upper and Lower Case, Thermal Conduction Cooling, Case Dimensions: 74L x 43.5W x 34H (mm). This Family features: Regulated output with very low ripple, Built-in Protection features: O.C.,S.C., O.V., Thermal, accepts Universal Input: 90-264Vac, meets Safety Agency Requirements: UL /cUL 1950 and TUV EN60950 and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B for ITE Applications. Model carries UL, cUL, Europe-Demko, CE, CB, Australia C-TICK and JAPAN PSE logos, and CE-Mark Report generated by independent Certified Laboratory. RoHS, WEEE and Energy Star compliant. In stock now. Modified and Custom Designs are Also Available.

GlobTekís GT-91080 Series of Power over Ethernet (PoE) Active Splitter & Injector are designed to function with and provide power to any IEEE 802.3 AF compliant PoE equipment. Regulated outputs voltage from: 5V to 24Vdc in 0.1V increment, up to 8-15W of continuous output power. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Upper and Lower Case, Thermal Conduction Cooling, Case Dimensions: 85L x 55W x 36H (mm). This Family features: Regulated output with very low ripple, Built-in Protection features: O.C., S.C., O.V, detection circuit, Thermal, accepts input voltage from -36 to -60Vdc (-48Vnom) with under -30V lock out voltage. Power & Data connectors can be installed to meet customerís requirements. Modified and Custom Designs are Also Available.

GlobTek's GT(M)200P200 series delivers up to 200W of Continuous Output Power Design has Regulated Output Voltages Ranging from: 3.3V to 48V in 0.1V increment with Remote Sense Available. This High Efficiency, 85% typ., Series of Power Supplies Features: Aluminum U-Channel Chassis with Optional Top Cover, 200W Convection Cooled or up to 350W with Forced Air, DC Power Good Signal, Remote Voltage Sensing, Current Share Capability, Active PFC to IEC 3000-3-2 Class A, accepts Universal Input: 90-264 Vac, Low Ripple, Class B EMI Filter, Built-in Protection: O.C./S.C., O.V., O.T., Footprint size starts at 196L x 107W x 46 mm. Meets Safety Agency Requirements: UL /cUL / TUV 60950/60601.1 and complies with EMC Directives for CE and FCC Class B Applications. All Models carry UL, DEMKO, PSE and CE Logos with Reports generated by independent Certified Laboratory. Modified and Custom Designs are Also Available

GlobTek's GT-41076 (up to 5W), GT-41052 (up to 15W) and GTM41060* ( up to 24W w/Constant Current option) series of Wall-Interchange Blade Wall Plug-In North America, Europe, U.K., Australia, China, Korea Class II, Double-Enforced Insulation Mechanical Configurations, Regulated Outputs voltage from: 5V to 48Vdc in 0.1V increment, up to 25W of continuous output power. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Upper and Lower Case, Thermal Conduction Cooling, Case Dimensions: 64L x 40.5W x 29H (mm). This Family features: Regulated output with very low ripple, Built-in Protection features: O.C., S.C., O.V., Thermal, accepts Universal Input: 90-264Vac, meets Safety Agency Requirements: UL /cUL 1950/*60601.1 and TUV EN60950/ *60601.1 and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B for ITE/Medical Applications. All Models carry UL, TUV and T-Mark logos and CE-Mark. Reports including CB are generated by independent Certified Laboratory. Modified and Custom Designs are Also Available.

GlobTek's GT(M)9250P270 series delivers up to 270W of Continuous Output Power Design has Regulated Output Voltages Ranging from: 3.3V to 48V in 0.1V increment with Remote Sense Available. This High Efficiency, 85% typ., Series of Power Supplies Features: Aluminum U-Channel Chassis with Optional Top Cover, 150W Convection Cooled or up to 270W with Forced Air, Active PFC to IEC 3000-3-2 Class A, accepts Universal Input: 90-264 Vac, Low Ripple, Class B EMI Filter, Built-in Protection: O.C./S.C., O.V., O.T., Footprint size starts at 111W x 208L x 42 mm. Meets Safety Agency Requirements: UL /cUL / TUV 60950/60601.1 and complies with EMC Directives for CE and FCC Class B Applications. All Models carry UL, TUV, PSE and CE Logos with Reports generated by independent Certified Laboratory. Modified and Custom Designs are Also Available.

GlobTek's GT(M)P9150/250/275 series delivers up to 275W of Continuous Output Power Design has Regulated Output Voltages Ranging from: 3.3V to 48V in 0.1V increment with Remote Sense Available. This High Efficiency, 85% typ., Series of Power Supplies Features: Aluminum U-Channel Chassis with Optional Top Cover, 150W Convection Cooled or up to 275W with Forced Air, Active PFC to IEC 3000-3-2 Class A, accepts Universal Input: 90-264 Vac, Low Ripple, Class B EMI Filter, Built-in Protection: O.C./S.C., O.V., O.T., Footprint size starts at 206L x 111W x 42 mm. Meets Safety Agency Requirements: UL /cUL / TUV 60950/60601.1 and complies with EMC Directives for CE and FCC Class B Applications. All Models carry UL, TUV, PSE and CE Logos with Reports generated by independent Certified Laboratory. Modified and Custom Designs are Also Available.

GlobTek Inc. GT-41060 series of Wall-Plug-In Interchangeable North America, Europe, U.K., Australia Class II, Double-Enforced Insulation Mechanical Configurations, Regulated Outputs voltage from: 5V to 24Vdc in 0.1V increment, up to 25W of continuous output power. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Case, Thermal Conduction Cooling, Case Dimensions: 80L x 55W x 34H (mm). This Family features: Regulated output with very low ripple, Built-in Protection features: O.C.,S.C., O.V., Thermal, accepts Universal Input: 90-264Vac, meets Safety Agency Requirements: UL /cUL / TUV 60950/60601.1 and complies EMC Directives for CE and FCC Class B Applications. All Models carry UL, TUV, PSE and CE Logos with Reports generated by independent Certified Laboratory. Modified and Custom Designs are Also available.

GlobTek Inc.'s is now offering Desk-Top/Wall Plug-in, 3.3-48V POE Injectors supplying up to 50W of power. Enclosed POE Injectors are housed in Impact Resistant non-vented Polycarbonate Case with Thermal Conduction Cooling. Products enclosure dimensions start at 74L x 49W x 40H (mm). Features: Universal Input:100-250VAC with Class I or Class II Protective Ground configurations, Regulated output with very low ripple, Built-in Protection: O.C./S.C., O.V., Thermal; meets Safety Agency Requirements: UL 60950, cUL 22.2NO.60950, TUV EN60950 AND cTUVus 60950, CE, EMC, AS/NZ 60950, DEMKO 60950, PCBC 60950, ARGENTINA TUV/S, CB; EMC Tested to comply with EN61000-3-2 EN610003-3 & EN50082-1 including EN61000-4-2 (system level), EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-11 LEVEL 4. Reports generated by independent Certified Laboratory. Modified and Custom designs are Also Available.

0-350 Watt 4"x 8" Power Supplies Meet Medical / ITE Applications

GlobTek's GT(M)200P350 series delivers up to 350W of Continuous Output Power Design has Regulated Output Voltages Ranging from: 3.3V to 48V in 0.1V increment with Remote Sense Available. This High Efficiency, 85% typ., Series of Power Supplies Features: Aluminum U-Channel Chassis with Optional Top Cover, 200W Convection Cooled or up to 350W with Forced Air, DC Power Good Signal, Remote Voltage Sensing, Current Share Capability, Active PFC to IEC 3000-3-2 Class A, accepts Universal Input: 90-264 Vac, Low Ripple, Class B EMI Filter, Built-in Protection: O.C./S.C., O.V., O.T., Footprint size starts at 196L x 107W x 46 mm. Meets Safety Agency Requirements: UL /cUL / TUV 60950/60601.1 and complies with EMC Directives for CE and FCC Class B Applications. All Models carry UL, DEMKO, PSE and CE Logos with Reports generated by independent Certified Laboratory. Modified and Custom Designs are Also Available.

62 (back to top)

GlobTek Inc. GT-41060 series of Wall-Plug-In Interchangeable North America, Europe, U.K., Australia Class II, Double-Enforced Insulation Mechanical Configurations, Regulated Outputs voltage from: 5V to 24Vdc in 0.1V increment, up to 25W of continuous output power. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Case, Thermal Conduction Cooling, Case Dimensions: 80L x 55W x 34H (mm). This Family features: Regulated output with very low ripple, Built-in Protection features: O.C.,S.C., O.V., Thermal, accepts Universal Input: 90-264Vac, meets Safety Agency Requirements: UL /cUL / TUV 60950/60601.1 and complies EMC Directives for CE and FCC Class B Applications. All Models carry UL, TUV, PSE and CE Logos with Reports generated by independent Certified Laboratory. Modified and Custom Designs are Also available.

60 (back to top)

GlobTek's GTD21114 series of 90W Desktop DC/DC Mobile Converter is ideal for mobile applications requiring higher power and stable DC power from vehicular or other DC power sources. 1-90 Watt Single-Output Series Switching Power Supplies are available in Car cigarette plug receptacle, Alligator clip, or multiple types of fastons/quick disconnect input Configurations. Designs are Class II, have Double-Enforced Insulation, and Output voltage from 12-26 Vdc in .1V increments. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Case, Thermal Conduction Cooling, Case Dimensions: 138.5L x 61W x 32.5 (mm) . These Families features: Regulated output with very low ripple, has Built-in Protection features: O.C./S.C., O.V., Thermal, accepts input voltage range 11-32 Vdc (others in design) and are Designed to meets Safety Agency Requirements: UL60950, CSA 22.2#950, and TUV EN60950 and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B ITE Applications. All Models carry CE-Mark Report generated by independent Certified Laboratory. Modified and Custom Designs are Also Available.

59 (back to top)

GlobTek's lines of External Power Supplies are now available in a spectrum of colors. These power supplies are approved to international safety agency requirements. Designs are available in Wall Plug-in and Desktop configurations with output wattage available up to 150W. The power supplies are ideal for Portable Equipment, Communication, Video, Power Tools, Consumer Electronics, Industrial and Medical Equipment. Many designs are available from stock. VERY Low Cost make these power supplies perfect for OEM requirements. Colored International Cordsets are also available.

58 (back to top)

GlobTek introduces EN60335-1 approved (CE & GS-marks) 50W, 12v power supplies. These power supplies are housed in Impact Resistant Polycarbonate Enclosure, Thermal Conduction Cooling, Case Dimensions: 119 X 60 X 32 MM. This Family features: Regulated output with low ripple up to 50W output power, Remote Sensing, has Built-in Protection features: O.C./S.C., O.V., Thermal, accepts Universal Input:100-250VAC, meets Safety Agency Requirements: Innova/GS to EN60335-1 (1st Edition) and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B, for Grounded, Class I or Class II ITE Applications. Input connector may be IEC60320/C8 or C14 or fixed CEE7/17 2 or 3 pole plug. Modified and Custom Designs, such as: Constant Current, Battery Chargers, Internal Applications: PCB and Open Frame Mounted are Also Available.

57 (back to top)

GlobTek Inc.GT-41052 series of Wall-Plug-In North America, Europe, U.K., Australia Class II, Double-Enforced Insulation Mechanical Configurations, Regulated Outputs voltage from: 5V to 24Vdc in 0.1V increment, up to 15W of continuous output power. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Upper and Lower Case, Thermal Conduction Cooling, Case Dimensions: 74L x 43.5W x 34H (mm). This Family features: Regulated output with very low ripple, Built-in Protection features: O.C.,S.C., O.V., Thermal, accepts Universal Input: 90-264Vac, meets Safety Agency Requirements: UL /cUL 1950 and TUV EN60950 and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B for ITE Applications. All Models carry UL, TUV and T-Mark logos, and CE-Mark Report generated by independent Certified Laboratory. RoHS production will be available 4/1/05 and Energy Star production on 5/1/05. Modified and Custom Designs are Also Available.

56 (back to top)

GT(M)21096-FW & GT(M)2065-FW series offers Protection Class II, double insulation.

GlobTek Inc. is introducing 2 new large series of single-output Class II (double-insulated) power supplies. Products with output voltage from: 3.3V to 48V in 0.1V increment, industry standard dimensions, some with optional power factor correction, remote sense, and other customizations upon request. These high efficiency, 85% typ., families of Open-Frame power supplies, have integral multi-fold heatsinks natural convection cooling, and In/Out Headers with Locking Ramp Connector for Open-Frame Configurations; accepts Universal Input: 90-264 VAC, features regulated output with low ripple, has Class B EMI Filter and P.F. Correction; also Built-in Protection features: O.C./S.C., O.V., O.T., meets Safety Agency Requirements: UL60950-1 (ITE) and UL60601-1 (Medical), CE Compliant for ungrounded (Class II) Applications. Modified and Custom Designs, such as: Constant Current, Battery Chargers and other Internal Applications are also available. Priced at under $6.00 in OEM quantities.

GlobTek's line of International Power Cordset are now available in Fluorescent colors. These cordsets are approved to international safety agency requirements. Designs are available in various lengths, cable types, conductor gauge, termination, and jacket color. Cordsets are ideal for Portable Equipment, Communication, Video, Power Tools, Consumer Electronics, Industrial and Medical Equipment. Many designs are available from stock. VERY Low Cost make these power supplies perfect for OEM requirements. Fluorescent colored International Power Supplies are also available.

GlobTek's "NEW" YP-18 Family of Right Angle Hospital Detachable Power Cordset Features Include: Complies with Ca. Proposition 65, Low Profile Exit from the Wall Receptacle, Overmolded 360 Degree Strain/Flex Relief available in 45 Degree Increments, Accepts SJT, SVT, SO, SJTO & SJTW Cord Types from 12~18 AWG, NEMA 5-15P "Green Dot" Hospital Plug which can be Terminated with Any Length of Cable to an IEC 320/C13 or C5 Plug (other Terminations are Available), Plug/Cable Colors Include: Black, White, Clear, or customer specified. Stock & Modified parts are Available.

47 (back to top)

GlobTek's GT(M)2065-80 series delivers up to 16.67 Amperes of continuous output power with 10CFM of airflow for 3.3vdc output applications, 11 Amperes for 5Vdc applications. Series has output voltages ranging from: 3.3V to 48V in 0.1V increment, single-platform design, industry standard, with Input Current-Shaper. This high efficiency, 85% typ., family of Open-Frame/ PCB Mount Style power supplies, has integral multi-fold heat sinks natural convection cooling, and In/Out Headers with Locking Ramp Connector for Open-Frame Configurations (non-locking headers for PCB Mount); accepts Universal Input: 90-264 Vac, features regulated output with low ripple, has Class B EMI Filter and P.F.C Correction; also Built-in Protection features: O.C./S.C., O.V., O.T. Packaged in an industry standard 3.0" X 5.0" X 1.3", the series is ideal for 1U applications. Certified or designed to meet International Safety Agencies for use with Medical UL/EN 60601.1 or Information Technology UL/EN 60950 Equipment applications. The series meets Conducted and Radiated EMI Class B and complies with the immunity requirements under EN61000 series of standards. It is available in open frame, open frame with wire harness, open base plate of any size and L-Bracket with perforated top cover.

46 (back to top)

400W Triple Output Hot Swappable Switchmode Power Supplies w/Parallel Function

GlobTek announces its NEW Open Frame 400W Switchmode Power Supplies w/Parallel Function. These low profile (348 x 129 x 57 mm) models offer up to 400W of regulated power. Designs have Active PFC (0.96min.), Built-In EMI Filter, Limiting AC Surge Current, Short Circuit / Overload Protection, Remote Sensing at all o/p's, Remote Shut Down, separate AC/DC/Fan "OK" Signals and the units can be Paralleled with each other for Hot Swappable redundant operation. Universal Wide Range Input of 85-264Vac 47-63Hz with outputs of +3.3/+5/+12Vdc @ 4/34/18 Amps (single, dual & modified o/p's are also available). UL Recognized to EN60950 3rd Edition, DEMKO Certified to EN60950, CE Approved with a CB Report Available. These 400W power sources are ideal for Tele/Data Communication, Video, Industrial or any system requiring 400W of power. Attractive Small Size, Proven Reliability and Cost Efficient makes these power supplies perfect for OEM requirements. Medical designs are also available.

15W Wall Plug-in Power Supplies have Interchangeable International Blades

GlobTek Inc.GT-41052 series of Wall-Plug-In North America, Europe, U.K., Australia Class II, Double-Enforced Insulation Mechanical Configurations, Regulated Outputs voltage from: 5V to 24Vdc in 0.1V increment, up to 15W of continuous output power. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Upper and Lower Case, Thermal Conduction Cooling, Case Dimensions: 74L x 43.5W x 34H (mm). This Family features: Regulated output with very low ripple, Built-in Protection features: O.C.,S.C., O.V., Thermal, accepts Universal Input: 90-264Vac, meets Safety Agency Requirements: UL /cUL 1950 and TUV EN60950 and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B for ITE Applications. All Models carry UL, TUV and T-Mark logos, and CE-Mark Report generated by independent Certified Laboratory. Modified and Custom Designs are Also Available.

March 2004

44 (back to top)

Small 20 Watt Open-Frame Power Supplies APPROVED Medical & ITE Applications

GlobTek’s GT(M)21096 series delivers 20W of continuous output power with free air convection cooling. Design has output voltages ranging from: 3.3V to 48V in 0.1V increment, single-platform design, industry standard, with Input Current-Shaper. This high efficiency, 85% typ., family of Open-Frame/ PCB Mount Style power supplies, has natural convection cooling, and In/Out Headers with Locking Ramp Connector for Open-Frame Configurations (non-locking headers for PCB Mount); accepts Universal Input: 90-264 Vac, features regulated output with low ripple, has Class B EMI Filter and P.F.C Correction; also Built-in Protection features: O.C./S.C., O.V. Packaged in an industry standard 84 X 41 X 28 mm. Certified to International Safety Agencies for use with Medical UL/EN 60601.1 or Information Technology UL/EN 60950 Equipment applications with documentation available. The series meets Conducted and Radiated EMI Class B and complies with the immunity requirements under EN61000 series of standards. It is available in external & wall plug-in international configurations. Priced at (call) in OEM quantities.

February 2004

43 (back to top)

Open-Frame (3x5) 80 Watt Power Supplies for Medical & ITE Applications

42 (back to top)

30W Switching Power Supplies with China CCC & broad worldwide Approval

Open-Frame (3x5)", 65 Watt Single-Output w/PFC Module Series Switch-ing Power Supplies

GlobTek Inc. is introducing our new large family, single-output models, output voltage from: 3.3V to 48V in 0.1V increment, single-platform design (3Wx5Lx1.2H)(in), industry standard, with Input Current-Shaper. This high efficiency, 85% typ., family of Open-Frame/ PCB Mount Style power supplies, has integral multi-fold heatsinks natural convection cooling, and In/Out Headers with Locking Ramp Connector for Open-Frame Configurations (non-locking headers for PCB Mount); accepts Universal Input: 90-264 VAC, features regulated output with low ripple, has Class B EMI Filter and P.F. Correction; also Built-in Protection features: O.C./S.C., O.V., O.T., meets Safety Agency Requirements: UL60950 (ITE) and UL2601 (Medical), CE Compliant for Grounded (Class I) and Non-Grounded Class II) Applications. Modified and Custom Designs, such as: Constant Current, Battery Chargers and other Internal Applications are also available. Priced at…. In OEM quantities.
Data Sheets:
GT(M)2065 Series, 30-65W, ITE and Medical (3X5)" Open Frame & PCB Mount

40 (back to top)

39 (back to top)

GlobTek's Desk-Top & Open-Frame 0-20 W Switchmode Power Supplies meet Medical/ITE/Class 2 Safety Requirements

GlobTek's 20W series of Desk-Top/Open-Frame Switchmode Power Supplies, accept Universal Inputs from 90-264Vac 47-63Hz and have Regulated Output ranging from 3.3V to 48V in 0.1V increment up to 0-20W of power with low Ripple. Features include: Class I Protective Ground and Class II Double-Enforced Insulation input configurations, Built-in Protection for O.C., S.C., O.V., OT. External power supplies are housed in a Impact Resistant non-vented Polycarbonate Case with dimensions of 86.5L x 47W x 32H (mm) Desk-Top or 84.6L x 30.7W x 28.9H (mm) Open-Frame/PCB Mount. All designs are Safety Agency Approved or Certified to UL2601/UL60950/UL1310, CSA 22.2 #601/950/223-M91, and TUV EN60601/EN60950 and complies with EMI/EMC Directives and FCC Class B, for Grounded and Non-Grounded, Medical and ITE Applications. All Models carry the UL, cUL, TUV, CE Logos. Stock, Modified and Custom Designs are Available. GlobTek is an ISO 9001:2000 Certified company.

38 (back to top)

Desk-Top 0-30 Watt Switching Power Supplies have IEC 320/C8 or C6 Inlets

GlobTek,Inc. presenting Single-Output Family GT-21148
Series of Desk-Top Power Supplies. Features Include: Class
I Protective Ground or Class II Double-Enforced
Insulation, Output Voltages from: 3.3V to 48V in 0.1V
increment up to 30W of Regulated Output Power, Built-in
O.C. / S.C., O.V. and Thermal Protection. Designs Accepts
Universal Inputs from 90-264Vac 47-63Hz and are Enclosed
in an Impact Resistant Non-Vented Polycarbonate Case 103L x 50W x 32H (mm). Meets Safety Agency Requirements:
UL1950, CSA 22.2#950, TUV EN60950 and Complies with EMI/RFI Regulations, EMC Directives for CE and FCC Class B, for Grounded or Non-Grounded ITE Applications. All Models carry UL/cUL, TUV logo's, with CE-Mark Report generated by independent Certified Laboratory. Modified and Custom Designs are Also Available.

GlobTek Inc.'s improved single-output family, GTM21097(CC) series is a Desk-Top Class I, Protective Ground, Double-Enforced Insulation Mechanical Configuration series. Output voltage from: 3.3V to 48V in 0.1V increment, from 36W to 50W maximum output power, single-platform design. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Upper and Lower Case with Thermal Conduction Cooling. Products enclosure dimensions are 86.5L x 47W x 32H (mm) Desk-Top or: 119 (4.7")L x 60(1.8")W x 32(1.2")H (mm). This Family features: Regulated output with very low ripple up to 50W output power, has Built-in Protection features: O.C./S.C., O.V., Thermal, accepts Universal Input:100-250VAC, meets Safety Agency Requirements: UL2601, CSA 22.2#601, and TUV EN60601 and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B, for Grounded medical applications. All Models carry UL, TUV, and CE-Mark Report generated by independent Certified Laboratory. (CC) version is available with constant current and other features for battery charging. Modified and Custom Designs are Also Available.

GlobTek Inc. is introducing three new single-output families of DC/DC converters ideal for mobile applications requiring higher power and stable DC power from vehicular or battery power sources. 1-56 Watt Single-Output Series Switching Power Supplies; GTD21088, GTD21109, GTD21148 series', Car cigarette plug receptacle, Alligator clip, or multiple types of fastons/quick disconnect input Configurations. Designs are Class II, have Double-Enforced Insulation, and Output voltage from: 3.3V to 48V in 0.1V increment, from 1W to 56W maximum output power. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Upper and Lower Case, Thermal Conduction Cooling, Case Dimensions: GTD21088: 57L x 48W x 26H (mm); GTD21108: 120.4L x 433.5W x 1H (mm); GTD21148: 103L x 50W x 22H (mm) . These Families features: Regulated output with very low ripple up to 56W output power, has Built-in Protection features: O.C./S.C., O.V., Thermal, accepts three input voltage ranges: 10-15VDC, 18-36 VDC, 36-72VDC and meets Safety Agency Requirements: UL60950, CSA 22.2#950, and TUV EN60950 and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B, for Non-Grounded, ITE Applications. All Models carry CE-Mark Report generated by independent Certified Laboratory. Modified and Custom Designs are Also Available.

GlobTek Inc. is introducing our new single-output family, GT-(A,R)81051-W2 series, North America, Europe, U.K., Australia Plug Configurations, of Class II, Double-Enforced Insulation, Output voltage from: 3.0V to 13V in 0.1V increment, 5 watts maximum output power, single-platform design. CV/CC (Constant-Voltage/ Constant-Current Limit) Models are derivative of Constant-Voltage, Current Limit standard models, and main applications Li-Ion battery chargers. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Upper and Lower Case, Thermal Conduction Cooling, Case Dimensions: Low Profile (R) 39.5Lx29.5Wx54H (mm) and Standard (A) 30.2Lx39.3Wx55.5H. This Family features: Regulated output with very low ripple up to 5W output power, has Built-in Protection features: O.C./S.C., O.V., Thermal, accepts Universal Input:100-250VAC, meets Safety Agency Requirements: UL60950, CSA 22.2#950, and TUV EN60601/EN60950 and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B, ITE/ Battery Charger Applications. All Models carry UL, TUV logo's, with CE-Mark Report generated by independent Certified Laboratory. Modified and Custom Designs are Also Available.
More Information...
Data Sheets:
GT-R81051 Series, 5W Single Output, Desktop & Wall Plug-In
GT-A81051 Series, 5W Single Output, Desktop & Wall Plug-In

GlobTek Inc. is introducing our new single-output family, GT(M)21089-W series, North America/Japan, Europe, U.K., Australia Plug Configurations, of Class I, Protective Ground and Class II, Double-Enforced Insulation, Output voltage from: 3.3V to 48V in 0.1V increment, from 10W to 20W maximum output power, single-platform design. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Upper and Lower Case, Thermal Conduction Cooling, Case Dimensions: 74L x 49W x 40.5H (mm). This Family features: Regulated output with very low ripple up to 20W output power, has Built-in Protection features: O.C./S.C., O.V., Thermal, accepts Universal Input:100-250VAC, meets Safety Agency Requirements: UL2601/UL60950/UL1310, CSA 22.2#601/950/223-M91, and TUV EN60601/EN60950 and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B, for Grounded and Non-Grounded, Medical and ITE Applications. All Models carry UL, TUV, T-Mark logo's, with CE-Mark Report generated by independent Certified Laboratory. Modified and Custom Designs are Also Available.

Data Sheets:
- GT(M)21089 Series, 10-20W, ITE and Medical Desktop & Wall   Plug-In
- GT221089 Series, 10-20W, Class 2 Power Unit, Desktop & Wall   Plug-In

GlobTek Inc. is introducing our new single-output family, GT(M)21089/21096 series, Desk-Top/Open-Frame, internal version of the enclosed family, of Class I, Protective Ground and Class II, Double-Enforced Insulation, Mechanical Configurations, Output voltage from: 3.3V to 48V in 0.1V increment, from 10W to 20W maximum output power, single-platform design. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Upper and Lower Case, Thermal Conduction Cooling, Case Dimensions: 86.5L x 47W x 32H (mm) Desk-Top or 84.6L x 30.7W x 28.9H (mm) Open-Frame/PCB Mount. This Family features: Regulated output with very low ripple up to 20W output power, has Built-in Protection features: O.C./S.C., O.V., Thermal, accepts Universal Input:100-250VAC, meets Safety Agency Requirements: UL2601/UL60950/UL1310, CSA 22.2#601/950/223-M91, and TUV EN60601/EN60950 and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B, for Grounded and Non-Grounded, Medical and ITE Applications. All Models carry UL, TUV, T-Mark logo's, with CE-Mark Report generated by independent Certified Laboratory. Modified and Custom Designs are Also Available.

Data Sheets:
- GT(M)21089 Series, 10-20W, ITE and Medical Desktop & Wall   Plug-In
- GT221089 Series, 10-20W, Class 2 Power Unit, Desktop & Wall   Plug-In
- GT(M)21096 Series, 10-20W ITE and Medical Open Frame &   PCB Mount

GlobTek Inc. is introducing our new single-output family, GT(M)21089/21096 series, Desk-Top/Wall-Plug-In North America, Europe, U.K., Australia/Open-Frame Class I, Protective Ground and Class II, Double-Enforced Insulation Mechanical Configurations, Output voltage from: 3.3V to 48V in 0.1V increment, from 10W to 20W maximum output power, single-platform design. Style enclosed power supplies are housed in Impact Resistant non-vented Polycarbonate Upper and Lower Case, Thermal Conduction Cooling, Case Dimensions: 86.5L x 47W x 32H (mm) Desk-Top or: 74L x 49W x 40.5H (mm) Wall-Plug-In all Models or 84.6L x 30.7W x 28.9H (mm) Open-Frame. This Family features: Regulated output with very low ripple up to 20W output power, has Built-in Protection features: O.C./S.C., O.V., Thermal, accepts Universal Input:100-250VAC, meets Safety Agency Requirements: UL2601/UL60950/UL1310, CSA 22.2#601/950/223-M91, and TUV EN60601/EN60950 and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B, for Grounded and Non-Grounded, Medical and ITE Applications. All Models carry UL, TUV and T-Mark logos, and CE-Mark Report generated by independent Certified Laboratory. Modified and Custom Designs are Also Available.

Data Sheets:
- GT(M)21089 Series, 10-20W, ITE and Medical Desktop & Wall   Plug-In
- GT221089 Series, 10-20W, Class 2 Power Unit, Desktop & Wall   Plug-In
- GT(M)21096 Series, 10-20W ITE and Medical Open Frame &   PCB Mount

GlobTek's newly updated "slim line" single-output family, WR9H(M)-series, sleek low-profile North America and Europe Wall Plug-In Configurations, Output voltage from: 3.0V to 48V in 0.1V increment, from 3W to 12W output power, single-platform design. This switcher family incorporates additional output ripple attenuator for less than 10mV and provides "Linear Performance at Linear Price" with advantage of "Low Profile Plug-In Side". Style power supplies is housed in Impact Resistant Polycarbonate Enclosure, Thermal Conduction Cooling, Case Dimensions: 57L x 48W x 26H (mm) or: 60L x 44W x 25H (mm), all Models. This Family features: Regulated output with very low ripple up to 12W output power, has Built-in Protection features: O.C/S.C., O.V., Thermal, accepts Universal Input: 100-250VAC, meets Safety Agency Requirements: UL60950, CSA 22.2#950, and TUV EN60950 and complies with EMI/RFI Regulations, EMC Directives/CE and FCC Class B, for Non-Grounded, Class II Double-Enforced Insulation, ITE Applications. All Models carry UL & TUV logos, and CE-Mark. Modified and Custom Designs, such as: Constant Current, Battery Chargers are Also Available.

Data Sheets:
- GT(M)21088/4101W Series, 5-12W, ITE and Medical,   Low-Profile Wall Plug-In

GlobTek Inc. is introducing our new large family, single-output models, output voltage from: 3.3V to 48V in 0.1V increment, single-platform design (3Wx5Lx1.2H)(in), industry standard, with Input Current-Shaper. This high efficiency, 85% typ., family of Open-Frame/ PCB Mount Style power supplies, has integral multi-fold heatsinks natural convection cooling, and In/Out Headers with Locking Ramp Connector for Open-Frame Configurations (non-locking headers for PCB Mount); accepts Universal Input: 90-264 VAC, features regulated output with low ripple, has Class B EMI Filter and P.F. Correction; also Built-in Protection features: O.C./S.C., O.V., O.T., meets Safety Agency Requirements: UL60950 (ITE) and UL2601 (Medical), CE Compliant for Grounded (Class I) and Non-Grounded Class II) Applications. Modified and Custom Designs, such as: Constant Current, Battery Chargers and other Internal Applications are also available. Priced at…. In OEM quantities.

Data Sheets:
- GT(M)2065 Series, 30-65W, ITE and Medical (3X5)" Open Frame   & PCB Mount

"GlobTek" Low-Profile Wall Plug-In, 5-12 Watt Single-Output Series Switching Power Supplies

GlobTek Inc. is introducing single-output family, GT-21088/4101W series, sleek low-profile North America and Europe Wall Plug-In Configurations, Output voltage from: 3.3V to 24V in 0.1V increment, from 5W to 12W output power, single-platform design. This switcher family incorporates additional output ripple attenuator for less than 10mV and provides "Linear Performance at Linear Price" with advantage of "Low Profile Plug-In Side". Style power supplies is housed in Impact Resistant Polycarbonate Enclosure, Thermal Conduction Cooling, Case Dimensions: 57L x 48W x 26H (mm) or: 60L x 44W x 25H (mm), all Models. This Family features: Regulated output with very low ripple up to 12W output power, has Built-in Protection features: O.C/S.C., O.V., Thermal, accepts Universal Input: 100-250VAC, meets Safety Agency Requirements: UL60950, CSA 22.2#950, and TUV EN60950 and complies with EMI/RFI Regulations, EMC Directives/CE and FCC Class B, for Non-Grounded, Class II Double-Enforced Insulation, ITE Applications. All Models carry UL, TUV and T-Mark logos, and CE-Mark Report generated by independent Certified Laboratory Modified and Custom Designs, such as: Constant Current, Battery Chargers are Also Available.

Data Sheets:
- GT(M)21088/4101W Series, 5-12W, ITE and Medical,   Low-Profile Wall Plug-In

Medical Power Supplies: External / Open Frame

GlobTek's new line of Medical Adaptors for Domestic, International & Universal applications. Designs include Wall Plug-in & Desktop styles: AC-DC Unregulated & Regulated AC-DC Switchmode power supplies up to 100W; Open Frame Regulated AC-DC Switchmode design up to 200W which include single through quad output configurations. All designs are approved or meet UL 2601.1, cUL 601.1, TUV/VDE EN60601.1 & CE requirements. These cost effective designs are ideal for OEM Medical products. International/Medical Power Cords are also available.

"GlobTek" Desktop 60 Watt Single-Output Series Switching Power Supplies

GlobTek Inc. is proud to introduce our new single-output family, GT-21126 series, output voltage from: 3.3V to 48V in 0.1V increment, single-platform design. This family of Desktop Style power supplies is housed in Impact Resistant Polycarbonate Enclosure, Thermal Conduction Cooling, Case Dimensions: 4.70L x 2.40W x 1.26H (in), all Models. This Family features: Regulated output with low ripple up to 60W output power, Remote Sensing, has Built-in Protection features: O.C./S.C., O.V., Thermal, accepts Universal Input:100-250VAC, meets Safety Agency Requirements: UL60950, CSA 22.2#950, and TUV EN60950 and complies with EMI/RFI Regulations, EMC Directives/ CE and FCC Class B, for Grounded, Class I ITE Applications. All Models carry UL, TUV and T-Mark/PSE-Mark logo's, and CE-Mark Report generated by independent Certified Laboratory. Modified and Custom Designs, such as: Constant Current, Battery Chargers, Internal Applications: PCB and Open Frame Mounted are Also Available.

International Detachable Power Cordset
Low Cost (2) Conductor IEC 320/C7

GlobTek's 2 Conductor IEC 320/C7 International Detachable Power Cordset. These cordsets are approved to international safety agency requirements. Designs are available in various lengths, cable types, conductor gauge, termination, and jacket color. Cordsets are ideal for Portable Equipment, Communication, Video, Consumer Electronics, Instrumentation and Home Use Medical Equipment. N. American, European, Australian & British cordsets are available from stock. VERY Low Cost make these power supplies perfect for OEM requirements. International Power Supplies are also available.

Desk-Top Fast-Charger, Ni-Cd/Ni-MH battery packs for ITE and Medical Applications

GlobTek Inc. is introducing our new family of External Switchmode Constant Current Split-Charge, two states: fast charge with charge termination and trickle charge end module. Fast Charge, 1C, Main Termination is achieved by Negative Delta Voltage or Delta Temperature Cut-Off and failsafe back-up: maximum temperature cut-off and 4-5 hours timer. Two Visual indicators are provided: Power-On and Charging using distinctive patterns to indicate the current charger status. This family is available in low profile 94V0 Polycarbonate plastic, no vents cases, size: 118L x 60W x 33H (mm), SMT/Through-Hole Components Single-Platform Design, has integral multi-fold heatsink thermal conduction cooling. Single Output, current regulated, are available up to 60W power, with outputs ranging from 1 cell to 48V battery configurations; accepts Universal Input: 90-264 VAC 47-63Hz, has Class B EMI Filter, meets Safety Agency Requirements: UL60950 and UL2601, CE Compliant. Modified and Custom Designs are also available.

Open-Frame 100 Watt Multi-Output w/PFC Module Series Switching Power Supplies.

GlobTek Inc. is introducing new large family, over 200 standard models, single, dual, triple and triple-low, output voltage from: 3.3V to 48V in 0.1V increment, single-platform design. This high efficiency, 85% typ., family of Open-Frame/ PCB Mount Style power supplies, size: 5.15L x 2.75W x 1.50H (in) has integral multi-fold heatsink natural convection cooling. The Triple-Low Model shown: +3.3V/3A, +5V/3A, +12V/6A accepts Universal Input: 90-264 VAC or 36-72 VDC, features regulated outputs with low ripple, has Class B EMI Filter and P.F. Correction; also Built-in Protection features: O.C./S.C., O.V., O.T., meets Safety Agency Requirements: UL60950 and UL2601, CE Compliant for Grounded and Non-Grounded Applications. Modified and Custom Designs, such as: Constant Current, Battery Chargers and other Internal Applications are also available.

External "Split-Rate Constant Current Sealed Lead Battery Chargers for Medical Applications; UL 2601-1 Recognized.

GlobTek is introducing our families of External Switchmode Split-Rate Constant Current Sealed Lead Battery Chargers. These designs are available in sleek low profile 94VO Polycarbonate, no vents plastic cases 118 x 60 x 33 mm to 141x76x43mm, SMT Leading Edge circuit designs, are thermal conduction cooled with regulated current, single output. For the first part of the charging period , while the battery is in low state of charge, the current charge will be medium to high charge rate, factory adjustable. When the battery is approaching full charge, the charging current is switched to a very low trickle charge rate. The charger then may be left connected to the battery indefinitely.
Designs are available up to 72W configurations. Universal input of 90-264 Vac 47-63Hz and outputs ranging from 1 cell to 48V battery. All designs are APPROVED to meet UL 2601-1, CSA (cUL22.2 #601.1), TUV EN60601, CE & CB. Designs were tested to EMC
requirements. These battery chargers are ideal for Portable Equipment, Communication, Video, Power Tools, and Other Electronic Medical & ITE Equipment. Attractive Small Size, Proven Reliability, Cost efficiency makes these power supplies perfect for OEM requirements (Modified designs & for use with ITE 60950 equipment are also available). International Power Cords are also available.

Open Frame Quad Output 200W
"High Reliability" Switchmode Power Supplies w/Active PFC (0.98 min)

GlobTek Open Frame 200W "High Reliability" Switchmode Power Supplies w/Active PFC. These low profile (178 x 108 x 30 mm) Integral Heatsink, convection-cooled models offer up to 200W of regulated power. Designs have Active PFC (0.98min.), Built-In EMI Filter Class B, Limiting AC Surge Current, Short Circuit / Overload Protection. Universal Wide Range Input of 85-264Vac 47-63Hz with single output units of 3.3-48Vdc and multiple output units up to quad are available.
See: 200W Open-Frame Rating Table and Open-Frame General Specifications
Designed to meet MTBF rating of 150,000+ hours at 50C w/o a fan. All designs are Approved or designed to meet international safety agency approvals (UL, cUL, TUV, CE, CB for ITE #UL60950 or Medical #UL2601-1) and EMC requirements. These power sources are ideal for Tele/Data Communication, Video, Industrial, Medical Equipment or any system requiring power. Attractive Small Size, Proven Reliability & Cost Efficient availability makes these power supplies perfect for OEM requirements. Modified & Custom designs Power Supplies up to 2000W are also available.

AC/DC Linear Medical Adaptors, Class I and II Wall Plug-in: North America, Euro, U.K., Australia

GlobTek is proud to introduce our Linear Medical Adaptors. These low cost Wall Plug-In designs can provide DC output up to 100W(custom, Dual Cord Desktop). Standard features: Within each model, Output may vary from 50mA to max. Load specified, in 50 mA increments, preserving output voltage +/- 5% tolerance. Options for specifying Output Voltage Deviation from standard model add suffix -x.x to model no. See specifications Dielectric Strength: 4000VAC pri-sec; Spacing 8mm pri-sec; Leakage:<0.100mA. Input Voltage of 120 or 220/230/240 VAC 50 or 60 Hz, Output Voltage ranging from 3-48Vdc & multiple Black Polycarbonate UL94V-0 enclosure required to UL 2601-1/ CSA (cUL) 22.2 #601.1 and TUV to EN0601. These power sources are ideal for medical Portable Equipment and other medical applications. Attractive Small Size, Proven Reliability, VERY Low Cost makes these power supplies perfect for OEM requirements. Modified & Custom are also available.

Medical Power Transformers AC to AC

GlobTek is proud to introduce our Medical Power Transformers. These low cost Wall Plug-In & Desktop designs can provide AC output up to 115 W. Standard features: 0-40C Operating Temperature, Short Circuit and Overload Protection, Input Voltage of 115 or 230 Vac 50 or 60 Hz, Output Voltage ranging from 3-30Vac & center tap, ABS plastic enclosed, Listed/Certified or designed to meet UL 2601.1 / CSA (cUL) 22.2 #601.1. These power sources are ideal for medical Portable Equipment, Communication, Video, and Power Tools. Attractive Small Size, Proven Reliability, VERY Low Cost makes these power supplies perfect for OEM requirements. Modified & Custom are also available.

External Desktop Switchmode Power Supplies up to 72W for Information Technology Applications

GlobTek's TR9 - series of Low-Profile External Desktop Switch-Mode Power Supplies integrate SMT Leading Edge circuit designs, are convection cooled with Universal input of 90-260 Vac 47-63Hz and regulated voltage outputs of 7.5, 12, 15, 24, 36, 48VDC. All designs are APPROVED to UL/cUL 1950, CE, TUV-GS, CB, MITI T-MARK, meet or exceed international EMC requirements. These power sources are ideal for Portable Equipment, Communication, Video, Power Tools, and Other Electronic Equipment. Attractive Small Size, Proven Reliability, Modified Designs are also available.

"GlobTek" Desktop 85- 100 Watt Multi-Output w/PFC Module (Standard Option) Series Switching Power Supplies

See Specification , Rating Table & Modular Concept for Desktop Power Supplies
GlobTek Inc. is proud to introduce our new large family, over 200 standard models, single, dual, triple and triple-low, output voltage from: 3.3V to 48V in 0.1V increment, single-platform design. This family of Desktop Style power supplies is housed in Impact Resistant Polycarbonate Enclosure, Thermal Conduction Cooling, Case Dimensions: 5.60L x 3.00W x 1.7H (in), all Models. This Family features: Regulated output with low ripple single/dual/triple up to 100W, Remote Sensing, has Built-in Protection features: O.C./S.C., O.V., Thermal, accepts Universal Input:100-250VAC, meets Safety Agency Requirements: UL60950 and UL2601, and complies with EMI/RFI Regulations, EMC Directives/ CE Compliant for Grounded and Non-Grounded Applications. Power Factor Correction (PFC) is available, standard option, to comply with EN61000-3-2 and EN61000-3-3. Modified and Custom Designs, such as: Constant Current, Battery Chargers, Internal Applications: PCB and Open Frame Mounted are Also Available.
See Specification , Rating Table& Modular Concept for Desktop Power Supplies

For more information please inquire:
Tel 201.784.1000 Fax 201.784.0111
Email: sales@ globtek.com

Power IEC 320 Inlets / Rewireable Plugs

These power components are approved to many international safety agency requirements. Designs are aavailable in various styles for various cable types, conductor guage sizes, terminations, and jackeets. Our "Polysnap IEC Module Sysstem" allows up to 388 combinations of IEC inlets, outlets, power on/off switches and fuse holders for hot/cold conditions. Waterproof Power Connectors are also available. These primary power components are ideal for Portable Equipment, Communication, Video, Power Tool, Consumer Electronics, Industrial and Medical Equipment. Many designs are available from stock. Low Cost make these power components perfect for OEM requirements. International Power Supplies are also available.

The latest additions to GlobTek extensive range of fuseholders include snap to panel fixing styles for 5x20mm and 6.3x32mm fuses. Allowing quick easy assembly into panels, the range omprises bayonet and screw cap styles with round or square bezels, all types are designed to snap securely to 1.0, 1.5, 2.0 or 3.0mm panels and conform to IEC127-6 category PC2. Finally the FX0418 is for 6.3x32mm fuses with screwdriver release screw cap, 6.3mm terminals and is rated at 16A, 250V. All types are manufactured from UL94V-0 flame retardant Nylon and glass filled Polyester materials, achieving an ac breakdown voltage of at least 2kV and an insulation resistance greater than 102M. Contact resistance is less than 10m.

International Power Cordset

GlobTek is offering wide range of International Power Cordset. These cordsets are approved to international safety agency requirements. Designs are available in various lengths, cable types, conductor gauge,termination, and jacket color. Cordsets are ideal for Portable Equipment, Communication, Video, Power Tools, Consumer Electronics, Industrial and Medical Equipment. Many designs are available from stock. VERY Low Cost make these power supplies perfect for OEM requirements. Catalog also available on www.GlobTek.

DC - DC Converters

GlobTek is proud to introduce our NEW family of DC - DC Converters. These
